HYDRAULIC PULLER-TENSIONER PT1250
Manual: MI-PT1250-050-01-IT Date: 06.11.2017 Author: AT Page: 54 of 69
To connect the machines, follow these step:
a. Choose the number of machine, push button n°1;
b. Connect the machine, passing commands from SLAVE to MASTER, push button n°2;
MACHINE STATUS N°1 (SLAVE)
MACHINE N°1 NOT CONNECT TO MACHINE N°2
BETWEEN THE DEDICATED BUTTON
BY MACHINE No. 1 PUTS THE CONTROLS TO
MACHINE No. 2
STATUS MACHINE N°1 (SLAVE)
CONNECT
TO
MACHINE N°2
(MACHINE MASTER WILL BE THE HIGHER NUMBER)
STATUS MACHINE N°2 (MASTER)
NOTE: TO CONNECT MACHINE 2 TO 1 DO NOT NEED
TO KNOW THE MACHINE CONNECTION BUTTON.
THE CONNECTION IS COMPLETED, PUTTING THE
CONTROLS FROM SLAVE TO MASTER
SCELTA
NUMERO
MACCHINA
CONFERMA
SCELTA
NUMERO
