TESTO 160 TH - Mounting and Battery Management

4 Operation
30
Signal Description
LED gives 1 green flash
(measurement data collected)
LED gives 2 short green flashes
(measurement data transmitted)
Send measurement data to the Testo
Cloud (website): press key < 3 sec
Measurement data transmitted
successfully
LED gives 4 red flashes
Batteries spent
LED flashes alternately green and red
Firmware update via USB or wireless
4.5 Inserting into/removing from the wall
bracket
1
- Insert the unlocking tool into the
unlocking opening.
2
-
Push back the locking pin using the unlocking tool.
3
- Pull the data logger up and out of
the wall bracket.
