Pin
No
PC Card Interface
Function
ATA Interface
Function
36 B_INPACK#
37 B_REG#,
38 B_SPKR# B_LED
39 B_STSCHG# B_PDIAG
40 B_D8 B_D8
41 B_D9 B_D9
42 B_D10 B_D10
43 B_CD2# B_CD2#
44 GND GND
45 PCMCIA#,
46 GND,
47 GND,
48 B_D3 B_D3
49 B_CD1# B_CD1#
50 B_D4 B_D4
51 B_D11 B_D11
52 B_D5 B_D5
53 B_D12 B_D12
54 B_D6 B_D6
55 B_D13 B_D13
56 B_D7 B_D7
57 B_D14 B_D14
58 B_CE1# B_CS0
59 B_D15 B_D15
60 B_A10 N.C.
61 B_CE2# B_CS1#
62 B_OE# 0
63 N.C. N.C.
64 B_A11 N.C.
65 B_IORD# B_IORD#
66 B_A9 B_CS1
Connector Pinouts
B-5
