Pin
No
PC Card Interface
Function
ATA Interface
Function
67 B_A8 N.C.
68 B_A13 N.C.
69 B_A14 N.C.
70 B_WE# N.C.
71 B_IREQ# B_IREQ
72 B_VCC B_VCC
73 B_VPP1 N.C.
74 B_A16 N.C.
75 B_A15 N.C.
76 B_A12 N.C.
77 B_A7 N.C.
78 B_A6 N.C.
79 B_A5 N.C.
80 B_A4 N.C.
81 B_A3 N.C.
82 B_A2 B_A2
83 B_A1 B_A1
84 B_A0 B_A0
85 B_D0 B_D0
86 B_D1 B_D1
87 B_D2 B_D2
88 B_IOIS16# B_IOCS16#
89 GND GND
90 N.C. N.C.
B-6
Connector Pinouts
