Table B-8 Memory Board Connector Pin Assignments (J13)
Main
Board
Pin No
Main Board
Pin Name
Main
Board I/O
Memory
Board
Pin No.
Memory
Board Pin
Name
1 BRAS3# Output 1 BRAS3#
2 BRAS2# Output 2 BRAS2#
3 BMA10 Output 3 BMA10
4 BMA9 Output 4 BMA9
5 BMA4 Output 5 BMA4
6 BMA1 Output 6 BMA1
7 BMA2 Output 7 BMA2
8 BMA3 Output 8 BMA3
9 BCAS1# Output 9 BCAS1#
10 BRAS0# Output 10 BRAS0#
11 BCAS0# Output 11 BCAS0#
12 BRAS1# Output 12 BRAS1#
13 BWE# Output 13 BWE#
14 BCAS3# Output 14 BCAS3#
15 BCAS2# Output 15 BCAS2#
16 BMA0 Output 16 BMA0
17 BMA8 Output 17 BMA8
18 BMA5 Output 18 BMA5
19 BMA6 Output 19 BMA6
20 BMA 7 Output 20 BMA 7
21 VCC Output 21 VCC
22 VCC Output 22 VCC
23 VCC Output 23 VCC
24 GND -- 24 GND
25 GND -- 25 GND
26 GND -- 26 GND
27 N.C. -- 27 N.C.
28 N.C. -- 28 N.C.
29 BHD30 I/O 29 BHD30
30 BHD31 I/O 30 BHD31
Connector Pinouts
B-7
