Texas Instruments Extensa 450 Series User Manual

Main
Board
Pin No
Main Board
Pin Name
Main
Board I/O
Memory
Board
Pin No.
Memory
Board Pin
Name
31 BHD29 I/O 31 BHD29
32 BHD28 I/O 32 BHD28
33 BHD27 I/O 33 BHD27
34 BHD26 I/O 34 BHD26
35 BHD25 I/O 35 BHD25
36 BHD24 I/O 36 BHD24
37 BHD23 I/O 37 BHD23
38 BHD22 I/O 38 BHD22
39 BHD21 I/O 39 BHD21
40 BHD20 I/O 40 BHD20
41 BHD19 I/O 41 BHD19
42 BHD18 I/O 42 BHD18
43 BHD17 I/O 43 BHD17
44 BHD16 I/O 44 BHD16
45 BHD15 I/O 45 BHD15
46 BHD14 I/O 46 BHD14
47 BHD13 I/O 47 BHD13
48 BHD12 I/O 48 BHD12
49 BHD11 I/O 49 BHD11
50 BHD10 I/O 50 BHD10
51 BHD9 I/O 51 BHD9
52 BHD8 I/O 52 BHD8
53 BHD7 I/O 53 BHD7
54 BHD6 I/O 54 BHD6
55 BHD5 I/O 55 BHD5
56 BHD4 I/O 56 BHD4
57 BHD3 I/O 57 BHD3
58 BHD2 I/O 58 BHD2
59 BHD1 I/O 59 BHD1
60 BHD0 I/O 60 BHD0
B-8
Connector Pinouts

Texas Instruments Extensa 450 Series Specifications

General

Brand	Texas Instruments
Model	Extensa 450 Series
Category	Laptop
Language	English
