Chapter 6
SNOU137–May 2015
EVM Bill of Materials
Item # Designator Part Number Manufacturer Description
1 !PCB1 SV601159 Any Printed Circuit Board
2 C1, C8, C10, C11, C1005X7R1H104K050B TDK CAP, CERM, 0.1 µF, 50 V, +/- 10%, X7R, 0402
C19, C21, C26, C27 B
3 C12, C14 C1005X7R1A224K050B TDK Corporation CAP, CERM, 220nF, 10V, 10%, X7R, 0402
B
4 C13 C0603C474K8RACTU Kemet CAP, CERM, 0.47uF, 10V, +/-10%, X7R, 0603
5 C15, C16 GRM1555C1H180JA01 MuRata CAP, CERM, 18 pF, 50 V, +/- 5%, C0G/NP0, 0402
D
6 C17 C1005X7R1H222K TDK CAP, CERM, 2200 pF, 50 V, +/- 10%, X7R, 0402
7 C18 C2012X5R1C226K125A TDK CAP, CERM, 22uF, 16V, +/-10%, X5R, 0805
C
8 C2 GRM155R61A105KE15 MuRata CAP, CERM, 1uF, 10V, +/-10%, X5R, 0402
D
9 C22, C24, C25 C0603C225K8PACTU Kemet CAP, CERM, 2.2uF, 10V, +/-10%, X5R, 0603
10 C3 C0603C153J3GACTU Kemet CAP, CERM, 0.015 µF, 25 V, +/- 5%, ,NP0 0603
11 C4, C5, C6, C7 GRM1885C2A180JA01D MuRata CAP, CERM, 18pF, 100V, +/-5%, C0G/NP0, 0603
12 C9, C20 C1608X5R1A106M TDK CAP, CERM, 10uF, 10V, +/-20%, X5R, 0603, CAP,
CERM, 10 µF, 10 V, +/- 20%, X5R, 0603
13 Csensor, Csensor2 CC0603FRNPO9BN391 Yageo America CAP, CERM, 390 pF, 50 V, +/- 1%, C0G/NP0, 0603
14 D1 MMSZ5232B-7-F Diodes Inc. Diode, Zener, 5.6V, 500mW, SOD-123
15 D2 LG L29K-G2J1-24-Z OSRAM LED, Green, SMD
16 D3 SML-LX0603SRW-TR Lumex LED, Super Red, SMD
17 J1 ZX62R-B-5P Hirose Electric Co. Ltd. Connector, Receptacle, Micro-USB Type B, SMT
18 J2 1727010 Phoenix Contact Conn Term Block, 2POS, 3.81mm, TH
19 J3, J5 TSW-102-07-G-S Samtec, Inc. Header, TH, 100mil, 2x1, Gold plated, 230 mil
above insulator
20 L1 VLS201610ET-100M TDK Inductor, Shielded, Ferrite, 10 µH, 0.4 A, 1.38 ohm,
SMD
21 LBL1 THT-14-423-10 Brady Thermal Transfer Printable Labels, 0.650" W x
0.200" H - 10,000 per roll
22 R1, R2 CRCW08050000Z0EA Vishay-Dale RES, 0 ohm, 5%, 0.125W, 0805
23 R10, R11 CRCW040210R0FKED Vishay-Dale RES, 10.0, 1%, 0.063 W, 0402
24 R12 ERJ-2GEJ152X Panasonic RES, 1.5k ohm, 5%, 0.10W, 0402
25 R13 CRCW04021M00JNED Vishay-Dale RES, 1.0 M, 5%, 0.063 W, 0402
26 R14 CRCW06030000Z0EA Vishay-Dale RES, 0 ohm, 5%, 0.1W, 0603
27 R3 CRCW06030000Z0EA Vishay-Dale RES, 0 ohm, 5%, 0.1W, 0603
28 R4 CRCW040233K0JNED Vishay-Dale RES, 33k ohm, 5%, 0.063W, 0402
29 R5, R6 CRCW04021K00JNED Vishay-Dale RES, 1.0k ohm, 5%, 0.063W, 0402
30 R7 RT0603BRD0749R9L Yageo America RES, 49.9, 0.1%, 0.1 W, 0603
31 R9 CRCW060333R0JNEA Vishay-Dale RES, 33 ohm, 5%, 0.1W, 0603
32 TP1 5001 Keystone Test Point, Miniature, Black, TH
33 U1 LDC1101DRC Texas Instruments 1.8V High Resolution Inductance to Digital
Converter, DRC0010J
34 U2 MSP430F5528IRGC Texas Instruments Mixed Signal MicroController, RGC0064B
