Texas Instruments LDC1101EVM - Introduction; Ldc1101 Evm

Chapter 1
SNOU137–May 2015
Introduction
The Texas Instruments LDC1101 evaluation module (EVM) helps designers evaluate the operation and
performance of the LDC1101 Inductance to Digital Converter. The EVM contains a low cost
MSP430F5528 microcontroller which comes with pre-loaded firmware to communicate with LabVIEW™
based PC controller software.
The EVM contains one LDC1101 soldered onto the EVM PCB.
Device and Package Configurations
Device IC Package
U1 LDC1101 VSON-10
Figure 1-1. LDC1101EVM
