Texas Instruments MSP430F5529

MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015 www.ti.com
Table 6-61. Port PJ (PJ.0 to PJ.3) Pin Functions
CONTROL BITS/
SIGNALS
(1)
PIN NAME (PJ.x) x FUNCTION
PJDIR.x
PJ.0/TDO 0 PJ.0 (I/O)
(2)
I: 0; O: 1
TDO
(3)
X
PJ.1/TDI/TCLK 1 PJ.1 (I/O)
(2)
I: 0; O: 1
TDI/TCLK
(3) (4)
X
PJ.2/TMS 2 PJ.2 (I/O)
(2)
I: 0; O: 1
TMS
(3) (4)
X
PJ.3/TCK 3 PJ.3 (I/O)
(2)
I: 0; O: 1
TCK
(3) (4)
X
(1) X = Don't care
(2) Default condition
(3) The pin direction is controlled by the JTAG module.
(4) In JTAG mode, pullups are activated automatically on TMS, TCK, and TDI/TCLK. PJREN.x are do not care.
