Texas Instruments MSP430F5529

MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015 www.ti.com
Table 6-9. System Module Interrupt Vector Registers (continued)
INTERRUPT VECTOR REGISTER ADDRESS INTERRUPT EVENT VALUE PRIORITY
019Ch No interrupt pending 00h
SVMLIFG 02h Highest
SVMHIFG 04h
SVSMLDLYIFG 06h
SVSMHDLYIFG 08h
SYSSNIV, System NMI VMAIFG 0Ah
JMBINIFG 0Ch
JMBOUTIFG 0Eh
SVMLVLRIFG 10h
SVMHVLRIFG 12h
Reserved 14h to 1Eh Lowest
019Ah No interrupt pending 00h
NMIIFG 02h Highest
OFIFG 04h
SYSUNIV, User NMI
ACCVIFG 06h
BUSIFG 08h
Reserved 0Ah to 1Eh Lowest
6.9.9 DMA Controller (Link to User's Guide)
The DMA controller allows movement of data from one memory address to another without CPU
intervention. For example, the DMA controller can be used to move data from the ADC12_A conversion
memory to RAM. Using the DMA controller can increase the throughput of peripheral modules. The DMA
controller reduces system power consumption by allowing the CPU to remain in sleep mode, without
having to awaken to move data to or from a peripheral.
The USB timestamp generator also uses the DMA trigger assignments described in Table 6-10.
Table 6-10. DMA Trigger Assignments
(1)
CHANNEL
TRIGGER
0 1 2
0 DMAREQ DMAREQ DMAREQ
1 TA0CCR0 CCIFG TA0CCR0 CCIFG TA0CCR0 CCIFG
2 TA0CCR2 CCIFG TA0CCR2 CCIFG TA0CCR2 CCIFG
3 TA1CCR0 CCIFG TA1CCR0 CCIFG TA1CCR0 CCIFG
4 TA1CCR2 CCIFG TA1CCR2 CCIFG TA1CCR2 CCIFG
5 TA2CCR0 CCIFG TA2CCR0 CCIFG TA2CCR0 CCIFG
6 TA2CCR2 CCIFG TA2CCR2 CCIFG TA2CCR2 CCIFG
7 TB0CCR0 CCIFG TB0CCR0 CCIFG TB0CCR0 CCIFG
8 TB0CCR2 CCIFG TB0CCR2 CCIFG TB0CCR2 CCIFG
9 Reserved Reserved Reserved
10 Reserved Reserved Reserved
11 Reserved Reserved Reserved
12 Reserved Reserved Reserved
13 Reserved Reserved Reserved
14 Reserved Reserved Reserved
15 Reserved Reserved Reserved
(1) If a reserved trigger source is selected, no Trigger1 is generated.
