Texas Instruments MSP430F5529

MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
www.ti.com SLAS590M –MARCH 2009–REVISED NOVEMBER 2015
Table 6-10. DMA Trigger Assignments
(1)
(continued)
CHANNEL
TRIGGER
0 1 2
16 UCA0RXIFG UCA0RXIFG UCA0RXIFG
17 UCA0TXIFG UCA0TXIFG UCA0TXIFG
18 UCB0RXIFG UCB0RXIFG UCB0RXIFG
19 UCB0TXIFG UCB0TXIFG UCB0TXIFG
20 UCA1RXIFG UCA1RXIFG UCA1RXIFG
21 UCA1TXIFG UCA1TXIFG UCA1TXIFG
22 UCB1RXIFG UCB1RXIFG UCB1RXIFG
23 UCB1TXIFG UCB1TXIFG UCB1TXIFG
24 ADC12IFGx
(2)
ADC12IFGx
(2)
ADC12IFGx
(2)
25 Reserved Reserved Reserved
26 Reserved Reserved Reserved
27 USB FNRXD USB FNRXD USB FNRXD
28 USB ready USB ready USB ready
29 MPY ready MPY ready MPY ready
30 DMA2IFG DMA0IFG DMA1IFG
31 DMAE0 DMAE0 DMAE0
(2) Only on devices with ADC. Reserved on devices without ADC.
6.9.10 Universal Serial Communication Interface (USCI) (Links to User's Guide: UART
Mode, SPI Mode, I
2
C Mode)
The USCI modules are used for serial data communication. The USCI module supports synchronous
communication protocols such as SPI (3-pin or 4-pin) and I
2
C, and asynchronous communication
protocols such as UART, enhanced UART with automatic baudrate detection, and IrDA. Each USCI
module contains two portions, A and B.
The USCI_An module provides support for SPI (3-pin or 4-pin), UART, enhanced UART, or IrDA.
The USCI_Bn module provides support for SPI (3-pin or 4-pin) or I
2
C.
The MSP430F55xx series includes two complete USCI modules (n = 0, 1).
