Texas Instruments MSP430F5529

MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015 www.ti.com
Table 6-54. Port P6 (P6.0 to P6.7) Pin Functions
CONTROL BITS OR SIGNALS
PIN NAME (P6.x) x FUNCTION
P6DIR.x P6SEL.x CBPD
P6.0/CB0/(A0) 0 P6.0 (I/O) I: 0; O: 1 0 0
A0 (only MSP430F552x) X 1 X
CB0
(1)
X X 1
P6.1/CB1/(A1) 1 P6.1 (I/O) I: 0; O: 1 0 0
A1 (only MSP430F552x) X 1 X
CB1
(1)
X X 1
P6.2/CB2/(A2) 2 P6.2 (I/O) I: 0; O: 1 0 0
A2 (only MSP430F552x) X 1 X
CB2
(1)
X X 1
P6.3/CB3/(A3) 3 P6.3 (I/O) I: 0; O: 1 0 0
A3 (only MSP430F552x) X 1 X
CB3
(1)
X X 1
P6.4/CB4/(A4) 4 P6.4 (I/O) I: 0; O: 1 0 0
A4 (only MSP430F552x) X 1 X
CB4
(1)
X X 1
P6.5/CB5/(A5) 5 P6.5 (I/O) I: 0; O: 1 0 0
A5 (only MSP430F552x) X 1 X
CB5
(1)
X X 1
P6.6/CB6/(A6) 6 P6.6 (I/O) I: 0; O: 1 0 0
A6 (only MSP430F552x) X 1 X
CB6
(1)
X X 1
P6.7/CB7/(A7) 7 P6.7 (I/O) I: 0; O: 1 0 0
A7 (only MSP430F552x) X 1 X
CB7
(1)
X X 1
(1) Setting the CBPD.x bit disables the output driver and the input Schmitt trigger to prevent parasitic cross currents when applying analog
signals. Selecting the CBx input pin to the comparator multiplexer with the CBx bits automatically disables output driver and input buffer
for that pin, regardless of the state of the associated CBPD.x bit.
