804 Appendix A: Functions and Instructions
Goto CATALOG
Goto
labelName
Transfers program control to the label
labelName
.
labelName
must be defined in the same program
using a
Lbl
instruction.
Program segment:
©
:0! temp
:1! i
:Lbl TOP
: temp+i! temp
: If i<10 Then
: i+1! i
: Goto TOP
: EndIf
:Disp temp
©
Graph CATALOG
Graph
expression1
[,
expression2
] [,
var1
] [,
var2
]
The
Smart Graph
feature graphs the requested
expressions/ functions using the current graphing
mode.
Expressions entered using the
Graph
or
Table
commands are assigned increasing function
numbers starting with 1. They can be modified or
individually deleted using the edit functions available
when the table is displayed by pressing
† Header
.
The currently selected Y= functions are ignored.
If you omit an optional
var
argument,
Graph
uses
the independent variable of the current graphing
mode.
Note: Not all optional arguments are valid in all
modes because you can never have all four
arguments at the same time.
In function graphing mode and
ZoomStd
window:
Graph 1.25aù cos(a),a
¸
In parametric graphing mode and
ZoomStd
window:
Graph
time,2cos(time)/time,time
¸
Some valid variations of this instruction are:
Function graphing
Graph
expr
,
x
Parametric graphing
Graph
xExpr
,
yExpr
,
t
Polar graphing
Graph
expr
,
q
Sequence graphing Not allowed.
3D graphing
Graph
expr
,
x
,
y
Diff Equations graphing Not allowed.
Note: Use
ClrGraph
to clear these functions, or go
to the Y= Editor to re-enable the system Y=
functions.
In 3D graphing mode:
Graph (v^2
ì w^2)/4,v,w
¸
4Hex MATH/Base menu
integer1
4Hex ⇒
integer
Converts
integer1
to a hexadecimal number. Binary
or hexadecimal numbers always have a 0b or 0h
prefix, respectively.
256 4Hex ¸ 0h100
0b111100001111
4Hex ¸ 0hF0F
