Table 6-49. McASP Registers Accessed Through Peripheral Configuration Port (continued)
BYTE ADDRESS ACRONYM REGISTER DESCRIPTION
0x01D0 010C DITCSRA3 Left (even TDM time slot) channel status register (DIT mode) 3
0x01D0 0110 DITCSRA4 Left (even TDM time slot) channel status register (DIT mode) 4
0x01D0 0114 DITCSRA5 Left (even TDM time slot) channel status register (DIT mode) 5
0x01D0 0118 DITCSRB0 Right (odd TDM time slot) channel status register (DIT mode) 0
0x01D0 011C DITCSRB1 Right (odd TDM time slot) channel status register (DIT mode) 1
0x01D0 0120 DITCSRB2 Right (odd TDM time slot) channel status register (DIT mode) 2
0x01D0 0124 DITCSRB3 Right (odd TDM time slot) channel status register (DIT mode) 3
0x01D0 0128 DITCSRB4 Right (odd TDM time slot) channel status register (DIT mode) 4
0x01D0 012C DITCSRB5 Right (odd TDM time slot) channel status register (DIT mode) 5
0x01D0 0130 DITUDRA0 Left (even TDM time slot) channel user data register (DIT mode) 0
0x01D0 0134 DITUDRA1 Left (even TDM time slot) channel user data register (DIT mode) 1
0x01D0 0138 DITUDRA2 Left (even TDM time slot) channel user data register (DIT mode) 2
0x01D0 013C DITUDRA3 Left (even TDM time slot) channel user data register (DIT mode) 3
0x01D0 0140 DITUDRA4 Left (even TDM time slot) channel user data register (DIT mode) 4
0x01D0 0144 DITUDRA5 Left (even TDM time slot) channel user data register (DIT mode) 5
0x01D0 0148 DITUDRB0 Right (odd TDM time slot) channel user data register (DIT mode) 0
0x01D0 014C DITUDRB1 Right (odd TDM time slot) channel user data register (DIT mode) 1
0x01D0 0150 DITUDRB2 Right (odd TDM time slot) channel user data register (DIT mode) 2
0x01D0 0154 DITUDRB3 Right (odd TDM time slot) channel user data register (DIT mode) 3
0x01D0 0158 DITUDRB4 Right (odd TDM time slot) channel user data register (DIT mode) 4
0x01D0 015C DITUDRB5 Right (odd TDM time slot) channel user data register (DIT mode) 5
0x01D0 0180 SRCTL0 Serializer control register 0
0x01D0 0184 SRCTL1 Serializer control register 1
0x01D0 0188 SRCTL2 Serializer control register 2
0x01D0 018C SRCTL3 Serializer control register 3
0x01D0 0190 SRCTL4 Serializer control register 4
0x01D0 0194 SRCTL5 Serializer control register 5
0x01D0 0198 SRCTL6 Serializer control register 6
0x01D0 019C SRCTL7 Serializer control register 7
0x01D0 01A0 SRCTL8 Serializer control register 8
0x01D0 01A4 SRCTL9 Serializer control register 9
0x01D0 01A8 SRCTL10 Serializer control register 10
0x01D0 01AC SRCTL11 Serializer control register 11
0x01D0 01B0 SRCTL12 Serializer control register 12
0x01D0 01B4 SRCTL13 Serializer control register 13
0x01D0 01B8 SRCTL14 Serializer control register 14
0x01D0 01BC SRCTL15 Serializer control register 15
