Table 6-49. McASP Registers Accessed Through Peripheral Configuration Port (continued)
BYTE ADDRESS ACRONYM REGISTER DESCRIPTION
(1) Writes to XRBUF originate from peripheral configuration port only when XBUSEL = 1 in XFMT.
(2) Reads from XRBUF originate on peripheral configuration port only when RBUSEL = 1 in RFMT.
0x01D0 0200 XBUF0
(1)
Transmit buffer register for serializer 0
0x01D0 0204 XBUF1
(1)
Transmit buffer register for serializer 1
0x01D0 0208 XBUF2
(1)
Transmit buffer register for serializer 2
0x01D0 020C XBUF3
(1)
Transmit buffer register for serializer 3
0x01D0 0210 XBUF4
(1)
Transmit buffer register for serializer 4
0x01D0 0214 XBUF5
(1)
Transmit buffer register for serializer 5
0x01D0 0218 XBUF6
(1)
Transmit buffer register for serializer 6
0x01D0 021C XBUF7
(1)
Transmit buffer register for serializer 7
0x01D0 0220 XBUF8
(1)
Transmit buffer register for serializer 8
0x01D0 0224 XBUF9
(1)
Transmit buffer register for serializer 9
0x01D0 0228 XBUF10
(1)
Transmit buffer register for serializer 10
0x01D0 022C XBUF11
(1)
Transmit buffer register for serializer 11
0x01D0 0230 XBUF12
(1)
Transmit buffer register for serializer 12
0x01D0 0234 XBUF13
(1)
Transmit buffer register for serializer 13
0x01D0 0238 XBUF14
(1)
Transmit buffer register for serializer 14
0x01D0 023C XBUF15
(1)
Transmit buffer register for serializer 15
0x01D0 0280 RBUF0
(2)
Receive buffer register for serializer 0
0x01D0 0284 RBUF1
(2)
Receive buffer register for serializer 1
0x01D0 0288 RBUF2
(2)
Receive buffer register for serializer 2
0x01D0 028C RBUF3
(2)
Receive buffer register for serializer 3
0x01D0 0290 RBUF4
(2)
Receive buffer register for serializer 4
0x01D0 0294 RBUF5
(2)
Receive buffer register for serializer 5
0x01D0 0298 RBUF6
(2)
Receive buffer register for serializer 6
0x01D0 029C RBUF7
(2)
Receive buffer register for serializer 7
0x01D0 02A0 RBUF8
(2)
Receive buffer register for serializer 8
0x01D0 02A4 RBUF9
(2)
Receive buffer register for serializer 9
0x01D0 02A8 RBUF10
(2)
Receive buffer register for serializer 10
0x01D0 02AC RBUF11
(2)
Receive buffer register for serializer 11
0x01D0 02B0 RBUF12
(2)
Receive buffer register for serializer 12
0x01D0 02B4 RBUF13
(2)
Receive buffer register for serializer 13
0x01D0 02B8 RBUF14
(2)
Receive buffer register for serializer 14
0x01D0 02BC RBUF15
(2)
Receive buffer register for serializer 15
Table 6-50. McASP Registers Accessed Through DMA Port
ACCESS
TYPE
BYTE
ADDRESS
ACRONYM REGISTER DESCRIPTION
Read
Accesses
0x01D0 2000 RBUF Receive buffer DMA port address. Cycles through receive serializers, skipping over transmit
serializers and inactive serializers. Starts at the lowest serializer at the beginning of each
time slot. Reads from DMA port only if XBUSEL = 0 in XFMT.
Write
Accesses
0x01D0 2000 XBUF Transmit buffer DMA port address. Cycles through transmit serializers, skipping over receive
and inactive serializers. Starts at the lowest serializer at the beginning of each time slot.
Writes to DMA port only if RBUSEL = 0 in RFMT.
