Table 5-8. Interrupt NVM Settings (continued)
Register Name Field Name
TPS65941120-Q1 TPS65941421-Q1 LP876411B5-Q1
Value Description Value Description Value Description
MASK_GPIO1_8
_FALL
GPIO1_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO2_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO3_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO4_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO5_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO6_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO7_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO8_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
MASK_GPIO1_8
_RISE
GPIO1_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO2_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO3_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO4_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO5_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO6_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO7_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO8_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
MASK_GPIO9_11
/
MASK_GPIO9_1
0
GPIO9_FALL_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO9_RISE_MA
SK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO10_FALL_M
ASK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO11_FALL_M
ASK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO10_RISE_M
ASK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
GPIO11_RISE_M
ASK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
MASK_STARTUP NPWRON_STAR
T_MASK
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
ENABLE_MASK 0x0 Interrupt generated 0x0 Interrupt generated 0x1 Interrupt not
generated.
FSD_MASK 0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
0x1 Interrupt not
generated.
SOFT_REBOOT_
MASK
0x0 Interrupt generated 0x0 Interrupt generated 0x0 Interrupt generated
Static NVM Settings www.ti.com
26 TPS65941120-Q1, TPS65941421-Q1 and LP876411B5-Q1 PMIC User Guide
for J721S2, PDN-0A
SLVUCJ9 – FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
