Texi Catenaccio User Manual

51
TEXI Catenaccio operation manual
Display Error Name Content of Error Solution
E 7 Machine Lock Error
The main-shaft of sewing
machine can’t rotate due to
some problem.
Turn off power and release the trouble
E 1 0 Pattern NO. Error
The prepared pattern number is
not registered in ROM or it is set
at unreadable. The pattern is 0.
Press RESET switch to confirm the
pattern NO. Confirm the content in
memory switch No.201.
E 3 0
Needle Rod Up
Position Error
The needle rod is not at UP
position.
Turn the hand pulley to return the needle
rod to its UP position.
E 4 0 Sewing Area Over
The sewing area is over the
limit.
Press RESET switch to confirm the X/Y
scale rate
E 4 3 Enlargement Error
The sewing stitch is below
10mm.
Press RESET switch and confirm the
pattern and X/Y scale rate.
E 4 5 Pattern Data Error
The pattern data cannot be
adopted.
Power off and check the data ROM
E 5 0 Pause
Press the RESET switch while
sewing machine is running.
The machine pauses.
Restart or return-to-origin after pressing
RESET switch for thread-trimming
E 2 2 0 Controller Abnormal
The communication with
executive device is abnormal.
Turn off the power and repower the
machine after a while.
E 3 0 2 Head Tilt Error
Head tilt detection switch is
turned ON.
The sewing machine cannot be operated
with the head tilted. Return the sewing
machine head to its proper position
E 3 0 3
Connection to
Main-shaft Fail
Can’t detection the highest point
of the sewing machine
Turn off the power, and check the
connection of the X5 plug.
E 3 0 5
Thread Trimmer
Position Error
Knife is not at proper position.
Turn off the power and check the CZ024
at the head signal circuit board.
E 3 0 6
Thread-catching
position error
The thread-catching device is at
wrong position.
Turn off the power and check the CZ026
at the head signal circuit board.
E 3 0 7
Thread-trimming
Motor Position Error
The thread-trimming motor is
not at the right position.
Check the thread-trimming device and
thread-trimming motor to make sure it
has no blockage.
E 7 3 3 Motor Reverse Motor Reverse
Turn off the power and check the
coupling of the main-shaft motor.
E 8 1 1 Overvoltage Error
The voltage of power is over the
specified value.
Confirm the voltage of power
E 8 1 3 Low Voltage Error The voltage of power is too low. Confirm the voltage of power.
E 9 0 1 Motor driver abnormal
The error is detected in motor
driver.
Turn off the power and repower the
machine after a while.
E 9 0 3
Power Supply of
Pulse Motor Error
Power supply of the pulse motor
is not output
Turn off the power and repower the
machine after a while.
E 9 0 4
Solenoid Power
Supply Error
Power supply of the solenoid
cannot output
Turn off the power and repower the
machine after a while.
E 9 0 7 X Origin Search Error X origin sensor doesn’t change.
Turn off power and check the connec-
tions of CZ021 on head signal circuit
board and X9 on control box.
List of Error Information
