TEXI Catenaccio operation manual
10. Set P Pattern & C Pattern
10-1. Use Pattern Key（ ）for Sewing
The saved patterns (No.1~200) can be registered on P1~P50. It is possible to change and register the scale rate, Max
speed limitation and sewing position. With the rolling window of pattern, user can also register patterns and has access to
the pattern from P1~P25 at a time.
For selecting P6~P25, user can use the combinations of (simultaneous pressing) shown in
the below table at his sewing.
(1). Registration on Pattern Key
Exp：Register pattern No.3 to P2, X scale rate: 50%; Y scale rate: 80%; Max speed limitation: 2000 rpm, pattern position:
0.5mm to the right and 1mm to the front.
P-No. Selection Key P-No. Selection Key P-No. Selection Key P-No. Selection Key
P1 P1 P8 P1+P4 P15 P4 +P5 P22 P2+P3+P4
P2 P2 P9 P1+P5 P16 P1+P2+P3 P23 P2+P3+P5
P3 P3 P10 P2+P3 P17 P1+P2+P4 P24 P2+P4+P5
P4 P4 P11 P2+P4 P18 P1+P2+P5 P25 P3+P4+P5
P5 P5 P12 P2+P5 P19 P1+P3+P4
P6 P1+P2 P13 P3+P4 P20 P1+P3+P5
P7 P1+P3 P14 P3+P5 P21 P1+P4+P5
1. Turn on the power, press (the sewing LED shall
be off at this moment) to have access to Mode Setting
(Setting of Storage Switch).
2. Use & to display the storage mode of
pattern
3. Press to have access to the pattern storage
mode.
4. Press to select the stored P-No.
This selection can also be done by using
& .
5. Use to select .
Use & to set pattern number.
To Next Page
