300/400TS and 300/400S 12 MAINTENANCE
12 – 4
4
3
11
7
2
13
12
14
9
6
5
10
1
8
No. DWG No. Parts name Reference page Part No.
CC1 Coupling Coil
12-20
2 CT2 Current Trans
12-29
3 CT3 Current Trans
12-29
4 FAN1 Cooling Fan
12-22
5 FCH1 Reactor
12-20
6 HCT1 Hall Current Sensor
12-27
7 L1 Ring Core
12-30
8 L105 Ring Core
12-30
R6 Current Limiting Resistor
12-18
10 R7 Resistor
11 R8 Resistor
SOL1 Solenoid Valve
12-23
13 TH1 Primary Thermistor
12-21
14 TH2 Secondary Thermistor
12-22
* 300/400TS only
1*
9*
12*
W7001382
W7001304
W7001304
W7001307
W7001681
10-5003
W7001309
W7001400
W7001451
W7001325
W7001325
10-6645
10-5228
10-5228
To Next Page
