300/400TS and 300/400S 12 MAINTENANCE
12 – 24
3) Remove the C-ring and detach the Solenoid Valve (SOL1).
When reinstalling, make sure that the C-ring seats in the Solenoid Valve groove.
3.23 Main ON/OFF Switch (S1)
1) Remove the Side Panel. [Reference page : 11-1]
2) Remove the six screws and six terminals.
3) Remove the two screws and detach the Main ON/OFF Switch (S1). Remove the three posts.
1
2
1
1
2
2
To Next Page
