cutmaster 82
Manual 0-4980 5-23 SERVICE
J1-9 /W1_ON Active low to enable W1 contactor L-M
J1-10 SHDN Active low enables PWM circuit
J1-11 /TRCH_SOL Active low to enable Torch Solenoid L-M
J1-12 /SOL_ON Active low to enable Power Supply solenoid L-M
J1-13 /OK_TO_MOVE Active low to enable OK_TO_MOVE (CNC) L-M
J1-14 /FAN_ON Active low to enable fans L-M
J1-15 /LATCH_ACTIVE Active low when Latch mode is active during cut L-M
J1-16 /TRCH_SW Active low = START is active -Torch switch, CNC M-L
J1-17 /PIP Active low = PARTS IN PLACE satisfied M-L
J1-18 AC_ON Pulse signal M-L
J1-19 CSR Active high during main transfer M-L
J1-20 /TORCH_SOL_DETECTED Active low for torch with remote solenoid M-L
J1-21 /OVERTEMP Active low when over temperature M-L
J1-22 V_IN Input Voltage signal M-L
3VDC = 460 VAC / 1.5VDC = 230VAC
J1-23 +12VDC M-L
J1-24 +12VDC M-L
J1-25 GND M-L
J1-26 GND M-L
J1-27 Not Used
J1-28 Not Used
J1-29 MAIN_BD_ID Voltage level to identify Main PCB = 1.1VDC M-L
J1-30 Not Used
J1-31 Not Used
J1-32 Not Used
J1-33 Not Used
J1-34 For Factory Use M-L
J1-35 For Factory Use M-L
J1-36 For Factory Use M-L
J1-37 For Factory Use M-L
J1-38 GND M-L
J1-39 For Factory Use M-L
J1-40 Not Used
