CUTMASTER 35mm, 40mm
INSTALLATION 3-4 Manual 0-5118
NOTE
For a secure seal, apply thread sealant to the fitting threads, according to the maker's instructions. Do Not
use Teflon tape as a thread sealer, as small particles of the tape may break off and block the small air passages
in the torch. Connect as follows:
Art # A-07944
Hose Clamp
1/4 NPT to 1/4"
(6mm) Fitting
Regulator/Filter
Assembly
Inlet Port
Gas Supply
Hose
Optional Single - Stage Filter Installation
