CUTMASTER 35mm, 40mm
INSTALLATION 3-6 Manual 0-5118
Using High Pressure Air Cylinders
When using high pressure air cylinders as the air supply:
1. Refer to the manufacturer’s specications for installation and maintenance procedures for
high pressure regulators.
2. Examine the cylinder valves to be sure they are clean and free of oil, grease or any foreign
material. Briey open each cylinder valve to blow out any dust which may be present.
3. The cylinder must be equipped with an adjustable high - pressure regulator capable of outlet
pressure 100 psi (6.9 bar) and ows of at least 300 scfh (141.5 lpm). For Maximum pressures
and Flows refer to the "Gas Requirements" chart in section 2T.03.
4. Connect supply hose to the cylinder.
NOTE
Pressure should be set at 100 psi (6.9 bar) at the high pressure cylinder regulator.
Supply hose must be at least 1/4 inch (6 mm) I.D.
For a secure seal, apply thread sealant to the fitting threads, according to manufacturer's instructions. Do Not
use Teflon tape as a thread sealer, as small particles of the tape may break off and block the small air passages
in the torch.
