Manual 0-2470 55 CUSTOMER/OPERATOR SERVICE
5.05 SERVICING TORCH LEADS COMPONENTS (continued)
Figure 5-H Torch Quick Disconnect Fitting - Front End View
Pins
3, 4
1, 6
13, 14
A
B
Description
Torch Switch
Parts-In-Place (PIP)
Shield (GND)
Pilot Return - Positive
Negative - Gas
AB
10
11
12 13 14
12
345
6
7
8
9
A-00018
