Thomas T175 - Quick - Tach 6.1

QUICK - TACH 6.1
6-2
6
C2649
Universal Quick - Tach Assembly
21
20
19
18
17
17
16
18
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1 Quick - Tack Assembly 12 Spring Stabilizer Bushing 2 Bolt, Hex 13 Compression Spring 3 Hardened Pin 14 Hex Bolt 4 Nylok Nut, Hex 15 Lock Pin Ass’y, R.H. & L.H. 5 Hardened Pin Ass’y 16 Hex Bolt 6 Grease Fitting 17 Stabilizer Bar Bushing 7 Plug 18 Flat Washer 8 R.H. & L.H. Handles 19 Spring Washer 9 Hardened Bushing 20 Hex Bolt 10 Linkage Block Bar 21 Lock Washer 11 Hex Nut
