6
- Playback of les cannot be guaranteed although extensions are listed, as it depends on
codec, data bit rate and resolution used (all MPEG codec formats are supported).
- Please ensure that either the USB device is already formatted to FAT/FAT32, or format the USB
device via your receiver, refer to chapter <USB> of the user manual available on our website
www.thomsonstb.net for details.
*This user manual describes the full functionality including the recording function and may not be applicable if the
software for recording via USB has not yet been installed.
2.0 YOUR RECEIVER
2.1 PIN code default: 0000
2.2 Front and side panel
Fig. 1
1. q Switch the receiver to Standby or On.
2. P-/P+ To change channels without using the remote control
3. Remote control sensor: Receives the signal from the remote control
4. Standby indicator: Shows power state of the receiver
Green LED - receiver is turned on
Red LED - receiver is in standby mode
2.3 Rear panel
Fig. 2
1. SAT IN To connect to the LNB of your satellite dish for reception
of satellite broadcast signal
2. USB For connection of USB device for Multimedia use
3. HDMI To connect to the HDMI input of your TV using a good
quality
4. TV SCART To connect to TV using a SCART cable
5. Audio L/R To connect to an analogue amplier for stereo audio.
6. S/PDIF coaxial To connect to a digital or home cinema audio amplier
7. Power connector The receiver requires a wall adapter, mains voltage input
100~240V AC 50~60Hz 12V, 1.5A DC output. Please
check the local power conditions before connecting the
receiver to the mains supply
2.4 Remote Control
Fig. 3
1. q Turns the receiver ON/Standby
2. ! To turn the sound on or o
3. 0-9 Channel number and numeric value input
4. TV/R Toggles between TV and radio mode
