8
32. RED Flexible functions in OSD menu and Teletext.
33. GREEN Flexible functions in OSD menu and Teletext. Changes
the picture resolution in viewing mode.
34. YELLOW Flexible functions in OSD menu and Teletext. Changes
the picture Aspect Ratio in viewing mode.
35. BLUE In viewing mode: displays the schedule menu for easy
setup timers; Flexible functions in OSD menu and
Teletext.
*This user manual describes the full functionality including the recording function and may not be applicable if the
software for recording via USB has not yet been installed.
2.5 Installing the batteries
Fig. 4
Remove the battery cover from the remote control and put 2x AAA size batteries inside the
compartment.
The diagram inside the battery compartment shows the correct way to install the batteries.
1. Open the cover
2. Install batteries
3. Close the cover
NOTE: The batteries should not be recharged, disassembled, electrically
short-circuited, be mixed or used with other types of batteries.
2.6 Using the remote control
Fig. 5
To use the remote control, point it towards the front of the digital receiver. The remote control
has a range of up to 7 metres from the receiver, if properly aligned towards the IR eye on the
front panel.
The remote control will not operate if its path is blocked.
Note: Sunlight or very bright light might decrease the sensitivity of the
remote control.
3.0 CONNECTIONS
3.1 Basic connection using an HDMI cable
Fig. 6
a) Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a
good quality coax cable and suitable ‘F-connector’ plugs.
b) Connect one end of a good quality HDMI cable to the HDMI output on your receiver and the
other end to the HDMI input of your TV.
c) Plug the power adapter to a suitable wall outlet.
