© 2013 Thorlabs GmbH
4 Programming (SDK)
245
With all other cameras, dwIoStatus is
empty. See dwIOStatus below.
WORD
wAOIIndex
AOI index (only AOI sequence mode of
DCC1240x)
WORD
wAOICycle
Readout cycles (only AOI sequence mode of
DCC1240x)
unsigned long long
u64FrameNumber
Internal image number
DWORD
dwImageBuffers
Number of image buffers existing in the
camera
DWORD
dwImageBuffersInUse
Number of image buffers in use in the
camera
DWORD
dwReserved3
Reserved
DWORD
dwImageHeight
Image height
DWORD
dwImageWidth
Image width
Status flags in UC480IMAGEINFO::dwIoStatus
Bit combination
State of digital input
State of GPIO 1
State of GPIO 2
000
0
0
0
001
0
0
1
010
0
1
0
011
0
1
1
100
1
0
0
101
1
0
1
110
1
1
0
111
1
1
1
Contents of the UC480IMAGEINFO::UEYETIME structure
WORD
wYear
Timestamp year
WORD
wMonth
Timestamp month
WORD
wDay
Timestamp day
WORD
wHour
Timestamp hour
WORD
wMinute
Timestamp minute
WORD
wSecond
Timestamp second
WORD
wMilliseconds
Timestamp millisecond
WORD
wReserved[2]
Reserved
Return values
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_INVALID_PARAMETER
One of the submitted parameters is outside the valid range or is not
supported for this sensor or is not available in this mode.
This may happen when e.g.:
more memory is allocated than the UC480IMAGEINFO structure
needs
nImageBufferID <= 0
pImageInfo == NULL
nImageInfoSize <= 0
IS_NO_SUCCESS
General error message
IS_SUCCESS
Function executed successfully
245
