Image formats of CCD sensors
Format
ID
Resolution
Name
Camera model
DCU-223x
DCU-224x
1
3264x2448
(8M)
2
3264x2176
(8M 3:2)
3
3264x1836
(8M 16:9)
4
2592x1944
(5M)
5
2048x1536
(3M)
6
1920x1080
(Full HD 16:9)
7
1632x1224
(2M)
8
1280x960
(1.2M 4:3)
X
9
1280x720
(HD 16:9)
X
11
960x480
(WVGA 2:1)
X
X
12
800x480
(WVGA)
X
X
13
640x480
(VGA)
X
X
14
640x360
(VGA 16:9)
X
15
400x240
(WQVGA)
X
16
352x288
(CIF)
X
17
288x352
(CIF Portrait)
X
18
320x240
(QVGA)
X
19
240x320
(QVGA Portrait)
X
20
1600x1200
(UXGA)
21
3840x2748
(10M)
22
1920x1080
(Full HD 16:9, HQ)
23
2560x1920
(5M)
24
768x576
(CCIR)
X
X
25
1280x1024
(1.3M SXGA)
X
26
2448x2048
(5M)
27
1024x768
(XGA)
X
X
28
1024x1024
(1M)
X
29
800x600
(SVGA)
X
X
30
1360x1024
(1.4M 4:3)
Return values
IS_CANT_ADD_TO_SEQUENCE
The image memory is already included in the sequence and cannot
be added again.
IS_BAD_STRUCTURE_SIZE
An internal structure has an incorrect size.
IS_CANT_COMMUNICATE_WITH_DRIVER
Communication with the driver failed because no driver has been
loaded.
IS_CANT_OPEN_DEVICE
An attempt to initialize or select the camera failed (no camera
connected or initialization error).
IS_CAPTURE_RUNNING
A capturing operation is in progress and must be terminated before
you can start another one.
IS_DR_CANNOT_CREATE_SURFACE
The image surface or overlay surface could not be created.
IS_DR_CANNOT_CREATE_TEXTURE
The texture could not be created.
IS_DR_CANNOT_CREATE_VERTEX_BUFFER
The vertex buffer could not be created.
