Page 49
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 4 Operating Instructions
Rev: 1.0, 18-Aug-2022 © 2022 Thorlabs
4.11.3.3 Data Export
Data can be accessed via connection to a PC via the USB connection.
Spec curves, screen shots, Data acquired in the Scope measurement screen or recorded via the Logging
feature, attenuation curved and the SCPI commands to write a custom made application are saved on the
PM5020 internal memory and can be conveniently viewed in a web browser.
1. Connect the PM5020 to a PC using the supplied USB cable.
2. Touch the icon SD Card in the Settings Menu .
This connects the PM5020 power meter to the PC.
3. A new removable disk will appear on the connected PC.
4. Open the subfolder of interest to access the data.
