Page 32
MTN028837-D02
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 4 Operating Instructions
Data can be displayed only or acquired and saved via the Logging or Scope displays and saved to the in-
ternal 8 GB memory of the PM5020 power meter. The saved data can be exported to the connected PC via
USB or the Ethernet Connection as described under Interface. Please find more information in the chapters
Logging and Scope.
4.11.1.3.2 Measurement Settings
Measurement settings can be changed via either of two panels, the full Settings Menu or the Side Panel
Menu.
Full Settings Menu:
The Settings Menu is best used when initially setting up the measurement as it includes all possible setting.
The full settings menu is opened by touching the following menu icon or by briefly pressing the soft button
next to it or via the pop-out side menu.
Side Panel Menu
