Page 50
MTN028837-D02
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 4 Operating Instructions
4.11.3.4 WYOA
The PM5020 power meter remote operation can be integrated into custom made systems with the help of
the provided SCPI commands and drivers.
The SCPI commands are saved on the PM5020 internal memory and can be conveniently viewed in a web
browser.
1. Connect the PM5020 to a PC using the supplied USB cable.
2. Touch the icon SD Card in the Settings Menu .
This connects the PM5020 power meter to the PC.
3. A new removable disk will appear on the connected PC.
4. Open the subfolder "support_docs" in a web browser (for example edge, firefox). This .html file con-
tains all information required to writer a custom made applications.
For PM5020 drivers, please either use NI-Visa drivers possibly already installed on the PC, or use the
Thorlabs TLP drivers which are installed with the Optical Power Monitor (OPM) software. The Thorlabs TLP
drivers are compatible with all other Thorlabs power meter drivers. Please see the manual for OPM for
more information.
