THORLABS PM5020 User Manual

Page 52
MTN028837-D02
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 5 Specifications
Item #
PM5020
Sensor Dependent
External Trigger
Connector
BNC (Front), 10-PIN PCB Connector Digital I/O (Rear)
(TTL 5V Max)
Analog Outputs
Connector
2 x BNC, Rear
Signal
CH1, CH2 Amplified, Corrected Input Signal
Voltage Range
-2.5 V to 10 V
Bandwidth
up to 250 kHz
Dependent on Sensor and Settings
Programmable Analog Output
Connector
4 x BNC, Rear
Signal
Selectable: CH1, CH2, CH1-CH2, CH1/CH2, Position X, Y
Voltage Range
-5 to 10 V; Programmable Gain and Offset
Bandwidth
up to 1 kHz
Dependent on Sensor and Settings
Shutter Control
Type
Support for SH05R(/M)/SH1(/M) with Interlock Input
Connector
Hirose HR10-7R-6S, 2.5mm Mono Audio
Power Rating
15 V, 0.5 A
Temperature Control
Type
NTC
Connector
2 Channels 2.5mm Stereo Audio &
10-PIN PCB Connector Fan Control (Rear)
Digital I/O
Type
4 configurable I/O Channels, 1 trigger in/output, I2C (LVTTL / TTL)
Connector
10-PIN PCB Connector Digital I/O (Rear)
Fan Control
Type
2 Channels, Voltage or rpm Control (12 V, 0.25 A)
Connector
10-PIN PCB Connector Fan Control (Rear)
Power Rating
12 V, 0.25 A
Interface
Type 1
USB 2.0
Connector
USB B, Rear
Type 2
Ethernet
Connector
RJ45, Rear
Type 3
Serial RS232
Connector
DE-9 Female, Rear
Power Supply
Line Voltage
100 - 240 V
Line Frequency
50 to 60 Hz
Maximum Power Consumption
30 W
Mains Supply Overvoltage
Category II (Cat II)
