22" FR1 & 26" FR2 Tilevision
®
Operating Instructions – June 2012 – Part No. TVS/00492/04 Ed 1.0
PORTER LANCASTRIAN LIMITED
www.tilevision.tv
22" TileVision
590mm x 381mm x 75mm depth
from the front face of the tiles.
26" TileVision
703mm x 455mm x 75mm depth
from the front face of the tiles.
Recess Dimensions
Speaker Dimensions
External Dimensions 240 mm Ø x 95 mm deep
Cutout Required 208 mm Ø
Speaker Depth 79 mm
Power Supply Dimensions
140mm x 65mm x 40mm depth
excluding connecting cables.
