3.2 Changing oil and filter
Engine oil: SAE 30
The required amount of oil
when changing the oil and oil
filter: approx. 1,7L
1. Drain the engine oil through the drain plug (A).
The drain plug can be loosend from the bottom
through the hole in the chassis
2. Replace the oil filter. Do not forget to lubricate the seal
with oil before instsalling a new filter. Tighten the filter by
hand.
3. Add oil – approx. 1,3L Start the machine, and let it run for
approx.2 minutes. Then add oil up to the line indicating the
maximum amount on the dipstick.
When changing oil and the oil filter, it is also necessary to
clean the oil cooler.
The oil cooler is located in the rear of the machine.
- Remove the steel grid in the rear.
- Remove the cooler and cleane it with compressed air.
- Mount the cooler and the steel grid again.
