4.1 Replacing the hydraulic filter
Method of replacing the hydraulic filter.
Important: Before you start working, it is important to clean the area around the filter to
prevent dirt from getting into the oil.
.
1. Lift the top hood, and set the cooler into the service position. With a single open ended wrench
(26 mm), loosen the stopper of the hydraulic tank.
2. Now you are able to gently loosen the filter unit by pulling on the black cover. If the movement is
too quick, the oil will spill over the edge.
3. Remove the stopper, and attach the new filter.
4. Then, after starting the machine, check the hydraulic oil level and add oil if necessary.
