9.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
When ordering replacement parts always give the following information:
•
Model & Serial Number of appliance
Installation date of appliance
Part number
Description of part
Finish
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
H41.1
*NOTE: • See Section 8.10 for rebrick placement.
APPLIANCE AND ACCESSORY REPLACEMENT PARTS
DESCRIPTION
HMFK-F12 FILTER, REPLACEMENT 12”X16”X1” 12/PKG
W010-2325 REPLACEMENT GLASS & GASKET
W010-2572 TRANSFORMER, 120V/24V/40VA
W010-2758 FAN & LIMIT CONTROL ASSEMBLY
*W018-0118 FIBRE BAFFLE “F”
W020-0043 GASKET DOOR KIT
W020-0563 GASKET GLASS KIT
*W090-0015 FIREBRICK “A” 1.25”x4.5”x9”
*W090-0018 FIREBRICK “F” 2.25”x1.250”x9”
*W090-0168 FIREBRICK “B” 4.50”x6.250”x1.25””
*W090-0179 FIREBRICK “E” 2.750”x9”x1.250”
W225-0214 BLACK DOOR
W325-0042 SPRING HANDLE - SMALL BLACK
W325-0043 SPRING HANDLE - LARGE BLACK
W385-0487 TIMBERWOLF LOGO
W435-0003 PRIMARY AIR SERVO MOTOR
W435-0049 BLOWER MOTOR, 1/6 - 1/12 HP PSC D164
W485-0047 PIN, HAIRPIN COTTER 0.093 X 2-1/2”
W562-0002 DOOR GASKET
W562-0004 GLASS GASKET
W580-0008 COMPLETE BRICK SET
W660-0113 SWITCH, VARIABLE SPEED (5A)
W690-0002 THERMODISC N/O @ 120DEG
W690-0005 THERMOSTAT, LINE VOLTAGE WALL
W710-0054 ASH LIP
W720-0155 REAR SECONDARY AIR TUBE
W720-0156 FRONT SECONDARY AIR TUBE
