W415-1133 / A / 06.12.13
52
FR
4.1.2 AJOUT DE SECTIONS
Ajoutez des sections de cheminée, selon les instructions d’installation des manufacturiers. La cheminée doit
dépasser le toit d’au moins 3’ (0,9m) de son point de contact avec la toiture, et 2’ (0,6m) de tout mur, toit ou
édi ce se trouvant à l’intérieur d’une distance horizontale de 10’ (3,1m).

3 FT
(0.9m)
MIN
3 FT
(0.9m)
MIN
10 FT
(3.1m) OR
MORE
FLAT ROOF
WALL
10 FT (3.1m)
TO NEAREST
ROOFLINE
RIDGE
LESS THAN
10 FEET
(3.1m)
2 FT (0.6m) MIN
3 FT
(0.9m)
MIN
2 FT (0.6m)
MIN
LESS THAN
10 FEET
(3.1m)
3 FT
(0.9m)
MIN
2 FT (0.6m)
MIN
DRAFT
Une cheminée isolée en acier inoxydable doit être supportée au plafond ou au toit et son installation doit être
conforme aux instructions de son fabricant.
