TINY AUDIO C10 User Guide
9
1.1 UV protection layer
If there is a UV protection layer across the top of the windshield then you must
place the DAB antenna with the Antenna at least 5cm below the layer.
1.2 Windshield wiper
For the best performance in the digital reception, the glass-mount antenna must
be placed outside of the swept area of the windshield wiper.
1.3 A Pillar and Windshield
The windshield usually has a black enamel band along the edges that contains a
border of dots and a black-shade area, the Signal Booster is to be installed next to
the dotted area along the side of the windshield. Open the A Pillar cover; the
remaining parts of the DAB antenna are to be installed on the metal frame and
inside the A Pillar cover.
Right Mount
Left Mount
A Pillar
A Pillar
