Description
Product 15
TK Elevator
BA, TW45 | 6231003860 | 03/2023
Item Designation Item Designation
1
Driving gear (vertical motor pos-
ition)
2
Traction sheave (D440 / D520 /
D590)
3
Motor (version with terminal box
for connection of the service
brake)
4
Service brake Mayr
RSZ125-2x50 Nm, including
mounted lever for manual re-
lease
5 Encoder 6 Handwinding wheel (D270)
7 Rope guard (adjustable) 8 Oil drain (3/4")
9
Oil filling hole and ventilation
(R3/4")
10
Oil level monitoring (gauge
glass)
11
Traction sheave mounting (ten-
sion disc with screwed connec-
tion)
12
Motor connection
(M16x1.5 / M25x1.5)
Brake connection
(2x M16x1.5)
13 Transport eyebolts 14
Mounting surface for machine
base frame
