Tomy MX-307 - Page 13

— 12 —
Displays/Indicator Lamps
Memory indicator lamp
Lights up when the memory selected is
retrieved.
Temperature display
Indicates temperature inside the
chamber. It also indicates the actual
value when the temperature is not
setting.
Speed/RCF display
Indicates the speed or the RCF. It also
indicates the set value while the rotor
stops spinning and the actual value
while spinning.
rpm/G unit indicator lamps
Alternately light up to indicate either
speed “rpm” or RCF “G” is displayed.
Time/Error code display
Indicates centrifugation time. It
indicates the set value while the rotor
stops and the remaining run time while
spinning. When an abnormality occurs,
an error code is displayed.
Lid open indicator lamp
Lights up when the lid is opened.
①
②
③
④
⑤
⑥
ECO indicator lamp
Lights up when the power saving (ECO)
mode is selected.
Soft brake indicator lamp
Lights up when the soft brake is set.
Function indicator lamp
While this lamp is on, each display on
the control panel indicates information
on status different from the normal
mode. Please refer to “7. FUNCTION
KEY”.
Flash indicator lamp
Lights up when the ash key is pressed
to start a short time run.
Start indicator lamp
Flashes during acceleration. When the
rotor has reached the set speed, it stops
ashing.
Stop indicator lamp
Flashes during deceleration. When the
rotor has stopped spinning, it ceases to
ash.
⑦
⑧
⑨
⑩
⑪
⑫
Control Keys
Memory keys
Press this key to store or retrieve the
data of operating conditions.
Temperature setting key
Press this key to set the temperature.
Speed/RCF setting key
Press this key to set the speed or RCF
and to alternately display speed and
RCF.
Time setting key
Press this key to set the run time or to
check the set time during spinning.
ECO key
Used to select the power saving (ECO)
mode.
Soft brake key
Press this key to select the natural
deceleration mode at the set speed or
lower.
A.
B.
C.
D.
E.
F.
Function key
Used to perform specic settings. Please
refer to “7. FUNCTION KEY”.
Jog dial
Used to alter each setting. After pressing
each setting key, turn the jog dial
counterclockwise to decrease the value
or clockwise to increase.
Flash key
Used to start a short time run.
Start key
Used to start operation.
Stop/Buzzer stop key
Used to stop operation.
G.
H.
I.
J.
K.
