11-5.
Specifications of the MX-307,MX-207 and MX-107
Model
MX-307 MX-207 MX-107
Maximum Speed 16,000rpm 15,000rpm
Maximum RCF 21,130G 21,130G 20,380G
Maximum Capacity 4×50ml 6×30ml 24×2ml
Control System Microprocessor control (feedback system)
Drive Motor Induction motor
Drive System Direct drive with an automatic alignment function
Data Entry Jog Dial
Temperature Setting Range
-9 to 35℃ (1℃ increments)
Speed Setting Range 300rpm to Maximum speed (100rpm increments)
RCF Setting Range 100G to Maximum RCF (100G increments)
Time Setting Range 0 to 99 minutes (1 minute increments) or
〈
F--
〉
for free
Additional Functions
FLASH (momentary spin) function, Memory function(two sets),
Previous setting memory, Soft Brake function, Power saving (ECO) mode.
Safety Devices
Lid interlock, Lid open/close detector, Over-speed detector,
Over-current circuit breaker, Motor over-current detector,
Abnormally high or low chamber temperature detector,
Rotor identification system, Imbalance detector.
Refrigerant HFC134a (250g) HFC134a (210g) HFC134a (200g)
Power Requirements
1 - Phase AC110/120V 50/60Hz 15A
1 - Phase AC220/230/240V 50/60Hz 8A
Rated Current
110/120V : 12A
220/230/240V : 6A
110/120V : 10A
220/230/240V : 5A
110/120V : 8A
220/230/240V : 4A
Breaker Rated breaking current 110/120V : 15A, 220/230/240V : 7.5A
Protection against
electric shock
Class I
Power Consumption
(Heat output)
920W (790kcal/h) 780W (670kcal/h) 650W (560kcal/h)
Dimensions
(except protruding portion)
345W×465D×860H mm
(table height:755H mm, lid in open position;1125H mm)
Net Weight
66kg (110/120V)
71kg (220/230/240V)
66kg (110/120V)
71kg (220/230/240V)
66kg (110/120V)
71kg (220/230/240V)
Environmental
Requirements
Ambient temperature range:10 to 35℃, Relative humidity:30 to 85%,
Atmospheric pressure:700 to 1060hPa
Accessories Included
Operator's manual × 1copy, Warranty card × 1copy, Hexagon wrench × 1pcs
Clear storage case × 1pcs, Attaching screw × 1pcs, Caster holder × 2pcs
Drain plug × 1pcs
