TH2883 Series Operation Manual Chapter 4 Introduction to [DISP]
4-3
range, choose the sample wave at the current frequency as the
standard wave and return to the main menu; if the compare
result is beyond the error range, an error information will
prompt and the instrument will keep in the wait state to Start a
new sample.
Start Start automatic test.
Return to previous page.
4.3.1.3 LOOP The instrument starts to sample standard waveforms, change frequency,
and cycle sampling.
Select Select the sample waveform at the current frequency as the standard
waveform.
Select & Check Compare the sample wave with the standard wave at the
current frequency, if the compare result is within the error
range, choose the sample wave at the current frequency as
the standard wave and return to the main menu; if the
compare result is beyond the error range, an error
information will prompt and the instrument will keep in the
wait state to Start a new sample.
Start Start loop test.
Return to previous page.
4.3.1.4 Modify Lighten the icon to enable the roller. Revolve the roller to choose or
modify the wave color, voltage and sample rate.
Revolve the roller to move the cursor to this zone and press the
roller for one time. Then rotate the roller to choose the wave color.
Revolve the roller to move the cursor to this zone. Then rotate the
roller to change the voltage by 10V. The voltage ranges from 100V
to 5000V.
Revolve the roller to move the cursor to this zone. Then rotate the
roller to select the desired sample rate.
4.3.1.5 Return to the main menu.
4.3.2 Compare
TH2883 series provides four kinds of compare methods as follows: Area Size Comparison,
Differential Area Comparison, Corona Discharge Comparison and Phase Differential
Comparison. The instrument collects the waveform data of 6000 points, thus user can select
the comparison area between the start position and 6000.
Press the Compare soft key to enter the main menu of it. Four compare methods can be set
under this menu.
【 N 】
Volt 1000
To Next Page
