TH2883 Series Operation Manual Chapter 5 Introduction to [SETUP]
5-2
Follow parameters can be set in <Setup>.
Impulse voltage (Imp Volt)
Sampling rate (Samp)
Test impulse (Test Imp)
Erase impulse (Erase Imp)
Voltage adjustment (Volt ADJ)
Wave display (Wave Disp)
Trigger mode (Trig Mode)
Delay time (Delay Time)
Breakdown voltage test (BDV)
Start voltage(Start Volt)
End voltage (End Volt)
Voltage step(Volt Step)
Comparator (Comparator)
Position (Position)
Limit (Limit)
State (State)
5.2.1 Imp Volt
The impulse voltage can be adjusted from 100V to 5000V by a resolution of 10V. Move the
cursor to the impulse voltage zone, following soft keys will be displayed.
They are coarse adjustment keys used to increase and decrease the voltage by a
resolution of 100V.
They are fine adjustment keys used to increase and decrease the voltage by a
resolution of 10V.
Lighten this key to enable the numerical arrow key. Respectively press 8, 2, 4, 6, the
cursor will move up, down, left and right.
Note: User can directly input the desired voltage by numerical keys. In the state of
inputting numbers, soft keys are unavailable. When the number is input, ENTER can be
used to end inputting and the default unit is volt (V).
5.2.2 Samp
200MSa/s, 100MSa/s, 50MSa/s, 25MSa/s, 12.5MSa/s, 6.25MSa/s, 3.12MSa/s, 1.56MSa/s are
optional for sample rate. Move the cursor to the sample rate zone, following soft keys are
available.
Be used to select the desired sample rate.
Lighten this key to enable the numerical arrow key. Respectively press 8, 2, 4, 6, the
cursor will move up, down, left and right.
