TH2883 Series Operation Manual Chapter 9 Handler interface
8-2
characters represents upper and lower bit of hexadecimal data for waveform data points (range of
the waveform data points: 0-255), the upper bit is followed by the lower bit. Users can make data
conversion after receiving the data. For example, the data can be converted to decimal data.
NOTE: once the waveform data query command is made, the host machine must be in the
receiving state at once in case of data losing.
REMARK: the tested waveform and standard waveform sampled are composed of 6000 data
points.
In figure 8-5-2, its data points are 1200. When compiling the upper machine software, these
1200 points can be acquired. The measured waveform (not standard waveform) can be
displayed on the upper machine.
