DISPLAYS AND SYMBOLS FOR SAFE USE
To encourage safe and proper use and to prevent danger to the operator and others or potential damage
to property, important cautionary messages are placed on the instrument body and inserted in the instruc-
tion manual.
We suggest that everyone using the instrument understands the meaning of the following displays, icons
and text before reading the "GENERAL SAFETY INFORMATION" and observes all listed instructions.
DISPLAYS
SYMBOL
*: for USA and Canada
Display Meaning
WARNINGS
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTIONS
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
NOTES
Useful functions to know. Paying attention to these will prevent the
problems noted.
Symbol
IEC/ISO
Publication
Description
IEC 60417-5032 Alternating Current
IEC 60417-5031 Direct current
IEC 60417-5957 For indoor use only
IEC 417-5265
“Off” (only for a part of
EQUIPMENT)
IEC 417-5264
“On” (only for a part of
EQUIPMENT)
ISO 7010-W001 General warning sign
ISO 7010-M002
Refer to the instruction man-
ual.
ISO 7000-2497 Date of manufacture
ISO 7000-2498 Serial number
Not applicable
WEEE Directive 2002/96/
EEC
Separate collection is neces-
sary
Symbol
IEC/ISO
Publication
Description
Not applicable
Polarity
Centre positive symbol
Not applicable The polarity of the batteries
ISO 7000-3082 Manufacturer
ISO 15223-1
Authorised Representative in
the European Community
VGA *
Used to enter the VGA sig-
nal. (This is not used when
using the product.)
DVI *
Used to enter the DVI signal.
(The image cable, which is
an accessory, is connected
to this.)
POWER *
Used to connect the AC
adapter. (The AC adapter,
which is an accessory, is
connected to this.)
