NOMENCLATURE
NOMENCLATURE
Front surface
Chart window: The patient watches the chart through this window.
Power switch/Pilot lamp: The pilot lamp indicates the power status of the instrument. The pilot
lamp is lit in orange when the instrument is plugged into the outlet.
When the power switch is turned ON, this lamp is lit in green and the
instrument can receive the image signal.
Maintenance cap: Use this in maintenance.
Sensor detector unit: This unit receives the signal from the alignment emitter to adjust the
eye position.
CAUTIONS
To avoid electric shock, do not touch the external connection terminal
and the patient at the same time.
