56
CHART FUNCTIONS UNIQUE TO THE MC-4S
3 Adjust the color selected on [Color to adjust] by changing [R], [G] and [B] within the range of 0 to
255.
Set "0", and the color ingredient is zero. Select "255", and the color ingredient is maximum.
4 When changing the value of [R], [G] and [B], the change is effectuated in the color of the MC-4S
screen at the same time. Adjust the object color while watching the screen.
The following table shows the points for the adjustment.
5 After adjusting the color, select the unadjusted item from [Color to adjust] and carry out Step 2
and 3.
Adjusted color Right eye (red lens) Left eye (green lens)
Red "Red" can be recognized as red.
The "Crossed area" can be assimi-
lated with "Red" and recognized as
red.
"Red" is assimilated with the back-
ground color on the screen.
Green "Green" is assimilated with the back-
ground color on the screen.
"Green" can be recognized as green.
The "Crossed area" can be assimi-
lated with "Green" and recognized as
green.
Background The background color is assimilated
with "Green" on the screen.
The background color is assimilated
with "Red" on the screen.
Crossed area The "Crossed area" can be assimi-
lated with "Red" and recognized as
red.
The "Crossed area" can be assimi-
lated with "Green" and recognized as
green.
NOTES
Touch the [Default] button among the function buttons. The set data for the
chart is returned to the setting when shipped.
