Topcon RL-SV2S - LS-80 L Display Indicators

4. Nomenclature
16
 LS-80L Display
$
The warning displays *1 and *2 are the functions that the
LS-80L detects alarm signal from the RL-SV2S.
The LS-80L can be canceled the alarm detection from the
RL-SV2S.
To be canceled the detection; Press the power switch
while pressing the buzzer sound switch when powering on.
Normal precision mode
High precision mode
Higher than datum position
(Buzzer sound:High frequent beep sound)
Move the sensor downward.
Datum position
(Buzzer sound:Continuous beep sound)
Lower than datum position
(Buzzer sound:Low frequent beep sound)
Move the sensor upward.
Battery remaining display
Height alert warning of rotating
laser
*1
Rotating laser battery
warning
*2
Battery is sufficient.
The power is low, but laser
is still usable.
Dead battery.
Replace the dry battery with
new one.
A flash shows that the RL-SV2S
power is low.
A flash and a buzzer sound
signifies that the height alert
function of the RL-SV2S is
