4. NOMENCLATURE
RL-SV2S Nomenclature
4.1 RL-SV2S
Control panel
Handle
Battery holder
Control panel
Carging connector (only in the
rechargeable battery type)
Sight
Rotary head
Beam apeature
Battery holder knob
Enter key
Power switch
X/Y axis
selection key/
Alignment key/
Up key
Menu key/
Escape key
Level vial
For Vertical
Rotation
Arrow keys
